INPUT: |
1 balanced mono microphone on a 3−pin terminal block connector. |
|
OUTPUTS: |
2 balanced mono line outputs on 3−pin terminal block connectors. |
|
MAX. OUTPUT LEVEL: |
27Vpp (22dBu). |
|
BANDWIDTH: |
>40kHz. |
|
S/N RATIO: |
81dB. |
|
CONTROLS: |
Mic. type selector pushbutton, −14dB to +68dB LINE OUT trimmers (master trimmer at max.), +37dB to +68dB master trimmer (line out trimmer at max.) |
|
COUPLING: |
Input, AC; output, DC. |
|
AUDIO THD + NOISE: |
0.18%. |
|
AUDIO 2ND HARMONIC: |
0.16%. |
|
POWER CONSUMPTION: |
12V DC, 220mA. |
|
DIMENSIONS: |
12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H. |
|
WEIGHT: |
0.3kg (0.66lbs) approx. |
|
INCLUDED ACCESSORIES: |
Power supply, mounting bracket |
|
OPTIONS: |
RK−3T 19" rack adapter. |
