INPUT:

1 composite video, 1Vpp/75Ω on a BNC connector.

OUTPUT:

1 composite video, 1Vpp/75Ω on a BNC connector.

MAX. OUTPUT LEVEL:

2.5Vpp.

BANDWIDTH:

500MHz.

DIFF. GAIN:

0.03%.

DIFF. PHASE:

0.03Deg.

S/N RATIO:

75dB.

CONTROLS:

Level: −0.8dB to 6.5dB; EQ.: 0dB to 8dB.

COUPLING:

DC.

POWER CONSUMPTION:

12V DC, 60mA.

DIMENSIONS:

5.32cm x 4.36cm x 7.25cm (2.09" x 1.72" x 2.85") W, D, H.

WEIGHT:

0.15kg (0.33lbs) approx.

INCLUDED ACCESSORIES:

Power supply.

OPTIONS:

RK-1 19" rack adapter.
