Bộ chia HDMI 1-16 và khuếch đại HDMI Kramer VM-16H

Liên Hệ

The VM-16H is a distribution amplifier for HDMI signals. It reclocks and equalizes the signal and distributes it to 16 identical outputs.

Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel).
HDTV Compatible.
HDCP Compliant.
HDMI Support - Deep Color, x.v.Color™, Lip Sync, CEC.
3D Pass-Through.
Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal integrity to travel longer distances.
I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
Active Output LED Indicators.
Worldwide Power Supply - 100−240V AC.
Standard 19” Rack Mount Size - 1U. Rack “ears” included.

Applications:

Bảo Hành:

12 Tháng

Tình Trạng

: Đang Có Hàng

Nhà Sản Xuất

INPUT:	HDMI Connector.
OUTPUT:	8/16 HDMI connectors.
BANDWIDTH:	6.75Gbps (2.25Gbps per graphic channel).
COMPLIANCE WITH HDMI STANDARD:	Supports HDMI and HDCP.
CONTROLS:	SELECT and READ buttons for selecting and storing EDID information.
INDICATOR LEDS:	OUTPUT STATUS 1 to 8/16.
OPERATING TEMPERATURE:	0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE:	−40° to +70°C (−40° to 158°F).
HUMIDITY:	10% to 90%, RHL non−condensing.
POWER CONSUMPTION:	100−240V AC, 50/60Hz 48VA.
DIMENSIONS:	19" x 7" x 1U W, D, H, rack mountable.
WEIGHT:	4.5kg (9.9lbs) approx.
INCLUDED ACCESSORIES:	Power cord.
