INPUT: |
1 mono microphone, 5mVpp/10kΩ on a 6.5mm phone jack. |
|
OUTPUTS: |
4 mono line level, 1Vpp/150Ω on 6.5mm phone jacks. |
|
MAX. OUTPUT LEVEL: |
4.8Vpp. |
|
AUDIO BANDWIDTH (-3DB): |
37kHz. |
|
GAIN CONTROL: |
5dB to 54dB. |
|
S/N RATIO: |
78dB. |
|
AUDIO THD + NOISE: |
0.1% @1kHz. |
|
POWER CONSUMPTION: |
12V DC, 20mA. |
|
DIMENSIONS: |
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H. |
|
WEIGHT: |
0.28kg (0.62lbs) approx. |
|
INCLUDED ACCESSORIES: |
Power supply, mounting bracket. |
|
OPTIONS: |
RK−3T 19" rack adapter. |
