INPUT:

1 RF, 0.5Vpp/75Ω (max.) on an “F” type connector.

OUTPUTS:

4 RF, 0.5Vpp/75Ω (max.) on “F” type connectors.

BANDWIDTH:

40MHz to 3000MHz (+/−3dB).

COUPLING:

AC.

RF GAIN:

+6dB typical across band.

NOISE FIGURE:

3.5dB.

POWER CONSUMPTION:

12V DC, 80mA.

DIMENSIONS:

12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H.

WEIGHT:

0.32kg (0.71lbs) approx.

INCLUDED ACCESSORIES:

Power supply, mounting bracket.

OPTIONS:

RK−3T 19" rack adapter
