| Type of CAT5 | Component Video Over CAT5 Transmitter(Tx)/Receiver(Rx) |
| Type of Signals | Component Video (YPBPR) Via 3x RCA connectors |
| CAT5 connection | Provided by the category5 Cable via RJ-45 connectors |
| Video Bandwidth | 225MHz(-3dB), 450MHz(-3dB) Large signal bandwidth |
| Output Balance Error | -60dB @ 50MHz |
| High isolation between Amplifier | 80dB @ 10MHz |
| Audio impedance | 10 Ohms |
| Audio Frequency response | 20Hz to 20KHz, +/-1dB |
| Color proofread | TINT and BRIGHTNESS adjustment. |
| Enclosure | Ear-Wall mounting attached |
| HD resolutions | 480i / 480p / 720p / 1080i and 1080p |
| CAT5 Extend distance | 100M (330FT) Maximum |
| Safety Approvals | CE, FCC, VCCI |
| Dimension (WxDxH) | 2.60" x 2.85" x 1.2" (70mm x 66mm x 29.1mm) |
| Power Supply | DC12V / 1A Max Use Universal Switch Type 50/60Hz, 100~240VAC |
| Weight | 0.17 kg / 0.37 lb |
